juice 2 phase decanter centrifuge

Food grade juice decanter centrifuge price

Our decanter centrifuge can used in soy protein separation plant .waste water treatment plan .and also applicable separation of liquid-solid from the olive oil,fish oil,avocado oil , coconut oil and so on . This centrifuge can continuously produce with a high production capacity and small energy consumption per unit,but also has the best separation effect,minimum material loss,most convenient operation and most economical installation and maintenance costs,the new light and heavy liquid phase distribution devices and reliable labyrinth seal structure are used to achieve the best oil and water separation,the advanced slag-discharge structure is also used to achieve the continuous and smooth solid phase slag discharge avoiding the occurrence of blocking materials ,while eliminating solid phase and water mixing in downtime. After the decanter’s drum and screw conveyor start to full speed.due to the high speed rotating generating a strong centrifugal force,Material from the feed pipe through the feed hole spiral cylinder into the drum,into the drum under the action of centrifugal force,larger specific gravity solid phase sink attached to the drum wall,forming an annual layer of solid phase,Screw conveyor under the action of the differential mechanism(The differential is to ensure the stability of differential speed device,dual frequency adjust speed devices shared bus,achieved drum speed and differential speed stepless adjustable,can adapt to changes in the flow, concentration,to ensure a good and stable separation effect ,spiral and drum produces a constant differential speed.The solid sediment dehydrated from the small end of the cone drum slag outlet launched,the proportion of light clear liquid from the cylinder end of the overflow overflow.So a continuous feeding, separation, slag, water, to achieve continuous separation effect.

2 phase Decanter Centrifuge:
After entering into the high-speed turning drum, the solid-phase particles in the mixed liquid run and settle on the drum
wall under the action of greatest centrifugal force; the light liquid settles at the innermost place of the drum under minimum centrifugal force; same as the drum's turning direction, a screw feeder also turns at a high speed, and a constant speed difference is generated by the differential mechanism, then the liquid will be discharged by the liquid outlet.
